2023 Prusa Bear MK4 3D Printer



The improved version of the Original Prusa i3MK3S+ Manufactured, assembled and fully calibrated locally in Australia!

FREE 14-DAY TRIAL PERIOD:

If you're not in love with this printer within 14 days, simply package it up and send it back for a full refund !!



FREE UPGRADE TO HIGH FLOW NOZZLE FOR FAST PRINTING

FREE 2x 1kg ROLLS OF HIGH QUALITY PLA+

FREE 100ML BED ADHESION SPRAY

FREE ANTI-VIBRATION RUBBER MAT

FREE 1 YEAR WARRANTY

FREE SHIPPING AUSTRALIA WIDE

CHOOSE THE COLOUR OF YOUR PRINTED PARTS - BLACK, WHITE, SILVER, TRANSPARENT, RED, ORANGE, YELLOW, GREEN, LIGHT BLUE, BLUE, PURPLE, VIOLET, PINK, BROWN, GLOW BLUE, GLOW GREEN, BLACK CARBON FIBRE, NYLON MJF OR EVEN 3D PRINTED ALUMINIUM!



Introducing the next generation of Prusa with over 10 years of revisions, modifications and design improvements, the Prusa BEAR MK4 takes what makes the i3 MK3S+ so reliable and pushes the boundaries into next-gen printing

Prusa Bear frame upgrade improves the stiffness and reliability of the Original Prusa i3 MK3S+ and allows for fasting prints, increased precision, easier maintenance and opens the door to more customisations.

The Prusa Bear MK4 offers the following advantages:

• Rigid frame and upgraded components make for a solid printer
• Modified with Klipper Firmware with 10,000mm/s^s acceleration and 200mm/s print speeds
• WiFi for wireless connectivity
• Print area bed levelling so you don't have to bed level the entire bed for one small print
• 3:1 geared extruder makes for super fast and super strong printing capabilities
• Light bar installed for full visibility
• Super silent
• Highly customisable
• Easier to maintain and customise
• Open source with a powerful community
• Fully compatible with PrusaSlicer
• Upgrade it to perform the function that you need (high temp enclosure, printing in flexible material, printing at high speeds etc)
• Australian support from a team with over 15 years of combined experience available all day, every day to answer any questions

We're so confident you will love this printer that you can make a purchase, use it for up to 2 weeks and if for any reason you feel that it doesn't meet your needs then bring it back for a full refund. You could have a project due and only need to print one thing, it could be too distracting, the wife might not like it etc etc whatever the reason is, as long as you bring it back within 14 days you'll get a full refund. That's how confident we are that you will love the printer and the support we provide.

Limited stock available



TECHNICAL SPECIFICATIONS

Build Volume	25×21×21 cm (9.84"×8.3"×8.3")
Layer height	0.05 - 0.35 mm
Nozzle	0.4mm high flow CHT nozzle
Filament Sensor	Yes
Automatic Bed Levelling	Yes, 7x7 mesh only over print area
Crash Detection:	Yes
Filament diameter	1.75 mm
Supported materials	Wide range of thermoplastics, including PLA, PETG, ASA, ABS, PC (Polycarbonate), CPE, PVA/BVOH, PVB, HIPS, PP (Polypropylene), Flex, nGen, Nylon, Carbon filled, Woodfill and other filled materials.
Max travel speed	5000+ mm/s
Max nozzle temperature	300 °C
Max heatbed temperature	120 °C
Extruder	Direct Drive 3:1 Geared Extruder, Bondtech gears, E3D V6 hotend
Print surface	Removable magnetic steel sheets (smooth, textured and satin available)
Printer dimensions (without spool)	7 kg, 50×55×40 cm
Power consumption	PLA settings: 80W / ABS settings: 120W



FULL FEATURE LIST (JULY 2023)

• Firmware: Klipper
• Controller: EINSY RAMBo 8-bit board  with Trinamic 2130 drivers (256 microstepping), co-developed with Ultimachine, sensorless homing for X and Y axes
• Mesh Bed Leveling: Advanced high-quality SuperPINDA sensor (Super Prusa INDuction Autoleveling sensor)
• Print sheet profiles: Firmware supports print sheet profiles to store Live Z calibration data to enable quick switching between different print sheets.
• Filament sensor: IR sensor built-in, supports filament auto-loading. Print pauses when filament runs out.
• Power Panic: Hardware-based, single G-code line accuracy
• Ethernet connection: via Raspberry Pi (optional)
• Wi-Fi connection: via Raspberry Pi (optional)
• Advanced sensors: 3 thermistors, fans RPM monitoring, SuperPINDA
• Calibration: Automatic, Mesh Bed Leveling, SelfTest
• Print medium: SD card (16 GB card included)
• Firmware update: via PC (USB cable)
• PSU: PSU with hardware-based power panic installed (resume print)
• Advanced features: Automatic filament loading, steel sheet profiles, Octoprint compatibility and more



LIST OF IMPROVEMENTS FROM THE Original Prusa i3 MK3S+ (20th October 2022)

• New P-fan duct for more efficient cooling
• Dual spool holder with filament guide and filament holder
• 4020 aluminium extrusions which span the entire footprint for superior rigidity
• Updated filament assembly for ease of maintenance
• X-axis and Y-axis now have belt tensioners
• All hotends come with a silicone sock
• Nickel-plated copper nozzle 0.4mm included
• 7x7 mesh bed levelling
• Extruder motor heatsink to improve motor performance



REFERENCE

Below are reference guides to the printer and how it is assembled. All mechanical parts, components and software comes open-source giving you the freedom and flexibility to tinker with the printer as you decide. The Prusa BEAR MK3S+ comes fully assembled, calibrated and runs a 24-hour print prior to dispatch. The printer is capable of self-adjusting and modifying the movement to suit any deformations that may have occurred during the build. Haribo gummy bears included :)

Frame Assembly Guide can be located HERE

Extruder Assembly Guide can be located HERE

GitHub Reference can be located here
